SPECIFICATIONS
Function	– Dim Sum Steaming
Form	– 1500 width x 1050 depth x (810 + 360 backsplash) height in mm
Construction	– Insulated flue-tube 60L heat exchanger with AISI444 for high efficiency of steam generation – One push button for flame failure device and ignition – Metal framework is made of AISI 304 stainless steel – Insulation underneath tabletop – 1 nos of swivel faucet mounted on backsplash
Engineering/ MEP ratings	– Type of Gas: LPG / NG / Town Gas, specify when ordering – Gas power: 56kW, at 0.5 psi – Gas connection size: DN20 – Water supply connection size: DN15 – Water drainage connection size: DN40 – Electrical connection for solenoid valve: 220V/SPN/50Hz/25W
Capacity	– 140 baskets of Dim Sum at maximum per time
Sanitation	– Extruded seamless table top – Removable perforated drainage for hygiene.
Accessories	– 7 hole plate with S/S tray stand – Full set Dim Sum Tray (stackable design with 4nos x S/S tray & 17” pan) – Rice roll adaptor
Safety	– Electromagnetic valve with instant gas cut off (<3s) – Extra width exhaust with cover design for reduction of CO – Water level detection and overheat protection
Special Requirements	– Recommended to install water filter and water softener (especially for HARD water zone) to prevent limescale formation. Please check with KEC for details
Option	– Gas regulator (recommended)

Back to products

YPT – Flame-Mate 2.0 – Double Unit – Dim Sum Steamer – ECS-2C

Environmental Steamer, Dim Sum Steamer – Double Unit

Download Data Sheet

Compare

Add to wishlist

SKU: ECS-2C Categories: Cooking Equipment / อุปกรณ์ทำอาหาร, Steamers / เตานึ่ง Tags: Cooking Equipment, Dim Sum Steamers, ECS-2C, Flame-Mate 2.0, Steamers, YPT, หม้อนึ่ง, หม้อนึ่งติ่มซ่ำ, เตาจีน, เตานึ่ง, เตานึ่งติ่มซำ

Description

SPECIFICATIONS
Function	– Dim Sum Steaming
Form	– 1500 width x 1050 depth x (810 + 360 backsplash) height in mm
Construction	– Insulated flue-tube 60L heat exchanger with AISI444 for high efficiency of steam generation – One push button for flame failure device and ignition – Metal framework is made of AISI 304 stainless steel – Insulation underneath tabletop – 1 nos of swivel faucet mounted on backsplash
Engineering/ MEP ratings	– Type of Gas: LPG / NG / Town Gas, specify when ordering – Gas power: 56kW, at 0.5 psi – Gas connection size: DN20 – Water supply connection size: DN15 – Water drainage connection size: DN40 – Electrical connection for solenoid valve: 220V/SPN/50Hz/25W
Capacity	– 140 baskets of Dim Sum at maximum per time
Sanitation	– Extruded seamless table top – Removable perforated drainage for hygiene.
Accessories	– 7 hole plate with S/S tray stand – Full set Dim Sum Tray (stackable design with 4nos x S/S tray & 17” pan) – Rice roll adaptor
Safety	– Electromagnetic valve with instant gas cut off (<3s) – Extra width exhaust with cover design for reduction of CO – Water level detection and overheat protection
Special Requirements	– Recommended to install water filter and water softener (especially for HARD water zone) to prevent limescale formation. Please check with KEC for details
Option	– Gas regulator (recommended)

Additional information

Brand	YPT
