Hoshizaki – Ice Machine – KMD-201AA

Hoshizaki KMD-201AA Crescent Ice Maker

DAILY ICE PRODUCTION CAPACITY OF UP TO 205KG

  Download Data Sheet

Compare
Add to wishlist
SKU: KMD-201AA Categories: , Tags: , , , , , , , ,
Description



DIMENSIONS (WxDxH):  560 x 625 x 610 mm

PACKED DIMENSIONS (WxDxH):  668 x 727 x 793 mm

WEIGHT (NETT/GROSS): 57 KG / 73 KG

AMPERAGE / STARTING AMPERAGE: 3.0A / 25A

ELECTRICAL CONSUMPTION: 700 W

REFRIGERANT CHARGE: R134a

HEAT REJECTION (AT32°C/WT21°C): 1410 W (1220 kcal/h)



OPERATING CONDITIONS: • Voltage Range:198V-254V • Ambient Temperature: 1°-40°C• Water Supply: 5°-35°C / 0.07-0.8 Mpa / 7.25-116 PSI • AC Supply Voltage: 1/220-240V / 50Hz



ICE PRODUCTION PER 24H (15MM)

(AT10°C/WT10°C)               205 KG

(AT21°C/WT15°C)               182 KG

(AT32°C/WT21°C)               157 KG



WATER CONSUMPTION PER 24H (AT21°C/WT15°C)

0.48 m3

2.6L / 1KG ICE



ICE PRODUCTION (AT21°C/WT15°C)

FREEZE CYCLE TIME         27.7 MIN

PER CYCLE           3.8 KG / 416 PCS
